Digital Signage

Viewsonic EP5542T

55 inch Multi-touch Digital ePoster

3840 x 2160 4K resolution
Infrared 10-point touch
Embedded media player and 16GB storage
USB multimedia playback
Remote settings

Category: Digital Signage Brand: Viewsonic

Sales Enquiry

Display
Panel Size	55″
Type/Tech	TFT LCD (VA type, DLED Backlight)
Display Area (mm)	1209.6 (H) * 680.4 (V)
Aspect Ratio	9:16
Native Resolution	2160 x 3840
Colors	1.07B
Brightness	450 nits (typ.)
Contrast Ratio	1300:1 (typ.)
Response Time	9 ms (typ. G to G)
Viewing Angles	H = 178, V = 178 typ.
Backlight Life	30,000 Hours Typ.
Surface Treatment	7H Tempered Glass
Orientation	Portrait
Touch
Type/ Tech	IR Recognition
Touch Resolution	32768 x 32768
Touch Point	10 Points
Input
HDMI	(2.0) x 3
RGB / VGA	x1
DisplayPort	(1.2) x 1
Audio	x1 PC audio (3.5 mm)
RS232	x1
Output
Audio	x1 (Earphone out)
SPDIF	x1
LAN
RJ45	x1
USB
Type A	x3 (2.0)
Type B	x2 (for touch module)
Speakers
Output	10W x 2
Compatibility
RGB PC/HDMI PC	1920×1080 @60Hz
HDMI	2160 x 3840 @60Hz
DisplayPort	2160 x 3840 @60Hz
System
Android Version	8.0
Multimedia	Image: JPG, BMP, PNG, Video: MP4, MOV, MKV, DAT, MPG, MPEG, AVI, TS, WMV, RM, RMVB, Audio: MP3, WAV, AAC
Bundle Software	Revel Digital, SureMDM
Voltage	100-240VAC +/- 10% Wide Range
Consumption	Normal 126 W, Max 149 W (max.), < 0.5W (Off)
Operating Conditions
Temperature (º C)	0°C to 40°C
Humidity	20% ~ 80% non-condensing
Dimensions (W x H x D)
Physical (inch / mm)	30.26 x 73.62 x 17.72 in / 768.5 x 1870 x 450 mm
Packaging (inch / mm)	38.19 x 80.08 x 23.98 in / 970 x 2034 x 609 mm
Weight
Net (lb / kg)	138.23 lbs / 62.7 kg
Gross (lb / kg)	164.69 lbs / 74.7 kg
Regulations
Compliance	cTUVus, FCC, Energy Star, CE, CB, RoHS, ErP, EEI, WEEE, BSMI
Package Contents
1. Power Cord 2. Remote control with battery 3. Quick Start Guide 4. Key

Overview

The ViewSonic EP5542T is a 10-point interactive 55” all-in-one free-standing digital ePoster kiosk with a sleek, slim design. Great for grabbing attention in busy, high-traffic areas, the EP5542T comes with a scratch-proof tempered glass faceplate for added durability. Featuring 4K resolution, 178°/178° wide-angle viewing, and dual 10W stereo speakers, the EP5542T delivers customized multimedia messaging with vivid clarity. Photo and video files can be played back using the embedded ARM media player and 16GB of internal memory, or add your own media player using the convenient media player cradle inside the lockable security door. It has build-in media playback software, as well as compatibility with ProAV control systems, make for easy management of multiple displays.

Interactive On-Demand Messaging

This display delivers on-demand interactive messaging with 10-point multi-touch capability and is the perfect e-catalog display solution for use as retail, information, and wayfinding kiosks in high-traffic areas.

All-in-one with Integrated Media Player

A powerful quad-core media player enables photo and video playback, while 16GB of onboard memory provides ample storage for files and multimedia content.

USB Multimedia Playback

Customised photos, music, and 4K video can be quickly displayed on-screen directly from a USB drive.

Access to Web Contents

Integrated with RJ45 connectivity, the display offers convenient web browsing functionality. Users can search online and watch videos directly on the display without having to connect to other computing devices.

Internal Scheduler

An efficient, user-friendly scheduling interface is available via the on-screen display (OSD). Setup features include time and date scheduling, ensuring that messaging, images, or videos run smoothly and on time.

Remote Various Display Management

Compatible with professional ProAV control systems such as Crestron, AMX, Extron, Control4, SureMDM, and Revel Digital, this ePoster allows IT personnel to manage and configure settings remotely over LAN with other display devices.

Media Player Cradle with Security Door

A convenient media player cradle can accommodate a PC or an additional mounted media player, while a lockable door keeps things secure and out of sight. The ePoster stand also features an integrated power supply, eliminating the need to find alternative outlets for add-on devices.

Dual 10W Speakers

Designed with dual integrated speakers, this display combines incredible screen performance with stereo sound for an immersive multimedia experience.

Premium Design

This standing all-in-one digital ePoster kiosk features a sleek and slim premium design utilising a 7H tempered glass faceplate that offers scratch-proof protection to keep your ePoster looking like new year after year.

4K Resolution

With four-times the resolution of Full HD, this Ultra HD 3840×2160 display delivers a breathtaking viewing experience with immersive images that are vibrant, clear, and as large as life.
