IFP

Viewsonic IFP7532

myViewBoard™ suite with whiteboard, wireless casting and remote device management
Front-facing dual speakers for better engagement
Pen-on-paper writing experience with Ultra Fine Touch Technology
Quad Core CPU powered by Android 9.0 OS
Low blue light certified

Category: IFP Brand: Viewsonic

Sales Enquiry

Panel
Panel Size	75″
Panel Type	TFT LCD Module with DLED Backlight
Display Area (mm)	1650.24mm(H) x 928.26mm(V) (74.6” diagonal)
Aspect Ratio	16:9
Resolution	UHD 3840×2160 (Pixels)
Colors	1.07B colors (10bit)
Brightness	350 nits (typ.)
Contrast Ratio	4000:1
Response Time	6.5ms
Viewing Angles	H = 178°, V = 178° typ.
Backlight Life	30,000 Hours (Min)
Surface Treatment: Hardness	9H Anti-glare coating
Orientation	Landscape
System & Performance
Processor	ARM quad-core Cortex-A55
RAM	2GB DDR4
Storage	16GB
Touch
Type/ Tech	Ultra Fine Touch Technology
Touch Point	20 points touch, 2 points writing
Inputs
HDMI	2.0 x2 (3840×2160 @60Hz) (HDMI2 port support ARC function)
RGB / VGA	x1
Audio	x1 (PC audio in)
RS232	x1
OPS	x1 (Optional Intel Standard OPS)
WiFi	Wifi slot: x1 (Optional VB-WiFi-002)
Outputs
Audio	x1 (Earphone out)
LAN	RJ45: x1
USB	Type A: USB2.0 Front x2 (SmartPort™ USB); Rear x2 Type B: x1 for HDMI/VGA touch
Audio
Speakers	15W x 2 subwoofers
Software
Embedded OS	Android 9
Basic Annotation Software	myViewBoard Whiteboard
Pro Annotation Software	myViewBoard Whiteboard for Windows (Embedded in optional Windows Slot-in PC)
Wireless Presentation	myViewBoard Display
All-in-one USB port	Front “SmartPort™ USB” to all channels.
Simple LAN sharing	10/100M for Android & Slot-in PC
Power
Light Sensor	Yes
Voltage	162-240VAC +/- 10%
Power Consumption	On: 238W (typ.) / Off: <0.5W
Ergonomics & Environment
Wall Mount (VESA®)	800×400
Temperature (°C)	0°C to 40°C
Humidity	10% ~ 90% RH non-condensing
Dimensions & Weight
Physical (W×H×D)	1710×1020×87 mm / 67.3×40.2×3.4 in
Packaging (W×H×D)	1860×280×1140 mm / 73×11×44.9 in
Net Weight	51.8kg / 114.2lb
Gross Weight	65.7kg / 144.8lb
Regulations
Certifications	BIS, CB, CE, LBL
Package Contents
1. Power cable (3 meters) 2. Remote control 3. USB cable (3 meters) 4. Touch pen x 2 5. Quick start guide 6. RS232 adapter 7. Clamp x 5 8. Screw x 8 9. HDMI cable (3 meters)
Compatible Slot-in PC
VPC12-WPO / VPC25 / VPC2C / VPC27

OVERVIEW

The ViewBoard® 32 series provides a comprehensive solution for schools and teachers looking to deliver more interactive and engaging lessons. The 4K UHD display features bonding technology for clearer colors and less glare. A 20-point touchscreen interface allows users to collaborate naturally either with a finger or one of the ViewBoard styluses. The built-in access to the myViewBoard suite brings together all of the hardware with a seamless software integration. The display also features Ultra Fine Touch Technology that delivers a paper-like writing experience with instant response and high accuracy, while dual-tip pen support allows you to simultaneously write or draw with two different colors. Users will also enjoy additional connectivity via the SmartPort™ USB and multi I/O ports, including HDMI/VGA, when looking to connect other devices for further classroom support. The included myViewBoard digital whiteboarding software combines enterprise-level security with cloud-based portability and annotation tools including simple, wireless casting capability with secure single sign-on, innovative collaboration tools, easy conversion of common files, and much more. Additionally, myViewBoard Manager offers a single-point management system capable of simultaneously controlling multiple displays.

Education essentials

Get a full suite of tools designed with educators in mind

Quick connection. Simple.

The myViewBoard Display allows wireless mirroring from compatible browsers on any network without cables or apps.

Flexible learning tools

Built-in the myViewBoard WhiteBoard makes collaboration easy.

Prepare a great lesson

Make your lessons stand out with a wide range of media and integration with a wide range of presentation tools.

Present the lesson

Make it easy to share and save all your lessons directly from the whiteboarding software right out of the box.

Participate in the lesson

Open lessons up to real-time participation with quizzes, polls, and student’s own multimedia contributions.

Efficient in remote management

The myViewBoard Manager for remote device management. Reduce IT workload with scheduled device updates, message broadcast, and system changes applied across multiple devices.

Easy collaboration

Designed for sharing ideas and student collaboration, the ViewBoard® 32 series include 20 touchpoints and ultra-fine touch dual-pen function without any setup. Automatically match colors and thicknesses to the pen without switching mode.

*Image shown is for illustration purposes only. Actual product may vary.

Surprising sound

Dual built-in 10W front-facing speakers take multi-media lessons to the next level.

Fully integrated inputs

Expand presentation capabilities and save time with multiple, easy-access HDMI, VGA, and USB ports.

Shared via USB port

SmartPort™ shared front USB ports for internal & external PCs.

A stand-alone computer

Unlock the full functionality of the ViewBoard® 32 series with an optional slot-in PC complete with Intel Core CPU standard OPS. All slot-in PC add-ons come preloaded with myViewBoard Whiteboard for Windows.

Web camera

Optional top-mounted webcam available for remote teaching and learning.

Fast Wireless Transmission

Optional Wifi module for the ViewBoard® 32 series. Support dual frequency 2.4GHz and 5GHz bandwidth, along with 802.11AC standard. It helps run lessons smoothly and get a better student engagement.
