MSI GeForce RTX™ 3060 VENTUS 3X 12G OC

Specification	Details
Model Name	GeForce RTX 3060 VENTUS 3X 12G OC
Graphics Processing Unit	NVIDIA® GeForce RTX RTX 3060
Interface	PCI Express® Gen 4
Core Clocks	Boost: 1807 MHz
CUDA® CORES	3584 Units
Memory Speed	15 Gbps
Memory	12GB GDDR6
Memory Bus	192-bit
Output	DisplayPort x 3 (v1.4a), HDMI x 1 (Supports 4K@120Hz as specified in HDMI 2.1)
HDCP Support	Yes
Power consumption	170W
Power connectors	8-pin x 1
Recommended PSU	550 W
Card Dimension (mm)	316 x 120 x 42 mm
Weight (Card / Package)	753 g / 1237 g
DirectX Version Support	12 API
OpenGL Version Support	4.6
Maximum Displays	4

Overview

The GeForce RTX™ 3060 VENTUS 3X 12G OC is a high-performance graphics card designed for gamers and content creators seeking smooth 1080p and 1440p gameplay with advanced ray tracing and AI capabilities. It features NVIDIA’s Ampere architecture, delivering strong performance with efficient triple-fan cooling in a sleek, durable design.

GPU and Memory
This card features 3584 CUDA cores with a boost clock of 1807 MHz, paired with 12GB of GDDR6 memory operating at 15 Gbps on a 192-bit memory bus. It provides high bandwidth and fast responsiveness for modern gaming and creative workloads.

Cooling System
The VENTUS 3X 12G OC comes with MSI’s award-winning TORX Fan 3.0 triple-fan design, creating high static pressure for optimal cooling. A large heatsink and numerous thermal pads ensure efficient heat dissipation, while Zero Frozr technology halts fans during low-load conditions for silent operation.

Key Features and Technologies

PCI Express Gen 4.0 interface
Display outputs: 3 x DisplayPort 1.4a, 1 x HDMI 2.1 (supporting 4K at 120Hz)
Real-time ray tracing and NVIDIA DLSS enabled by second-generation RT cores and third-generation Tensor cores
Maximum resolution: 7680 x 4320 with support for up to 4 simultaneous displays
Compatibility with DirectX 12 Ultimate, OpenGL 4.6, NVIDIA G-SYNC, and adaptive vertical sync
MSI Center software for monitoring and optimization
Power consumption around 170W; powered by a single 8-pin connector
Card dimensions: 316 x 120 x 42 mm; weight approximately 753 grams
3-year manufacturer warranty

Build Quality and Design
The card features a brushed-finish backplate and custom PCB designed for durability and reliability. Its triple-fan cooling system and robust heatsink ensure excellent temperature control.

Performance and Compatibility
Optimized for smooth gameplay and creative performance at high settings, the RTX 3060 VENTUS 3X 12G OC supports demanding modern games and professional workloads with enhanced RTX and AI features.

Conclusion
The GeForce RTX™ 3060 VENTUS 3X 12G OC delivers balanced power, superior cooling, and advanced functionality in a compact triple-fan design, making it an excellent choice for gamers and creators wanting reliable, high-efficiency performance.
