Kodak S2070 Scanner

  • RESOLUTION: 600 dpi
  • SPEED: 70 ppm | 80 sheets ADF
  • DAILY VOLUME: Up to 10,000 pages per day
  • CONNECTIVITY: USB 3.2 GEN 1 (backward compatible with USB 2.0 & USB 3.0)

Compatible with optional accessories.

Category: Brand:
Sales Enquiry
Specifications Details
Recommended Daily Volume Up to 10,000 pages per day
Throughput Speeds* Black-and-white / Grayscale / Color: up to 70 ppm / 140 ipm at 200 and 300 dpi
Scanning Technology Dual CIS; Grayscale output bit depth: 256 levels (8-bit); Color output: 24 bits (8 x 3)
Processor Embedded Dual Core Cortex A15 with Dual DSP Image Processors and Multiple Cortex M4 Sub-processors
Operator Control Panel 1.5-inch color LCD
Optical Resolution 600 dpi
Illumination Dual RGB LEDs
Output Resolution 75 / 100 / 150 / 200 / 240 / 250 / 300 / 400 / 500 / 600 / 1200 dpi
Max./Min. Document Size** Maximum: 216 mm x 356 mm (8.5 x 14 in.)
Minimum: 52 mm x 52 mm (2.08 x 2.05 in.)
Long document: 216 mm x 3000 mm (8.5 x 118 in.)
Paper Thickness & Weight 27–433 g/m² (7.2 lb. bond – 160 lb. cover stock); ID cards up to 1.4 mm (0.55 in.) thick
Feeder Up to 80 sheets (20 lb. / 80 g/m²); handles small docs (A8, ID cards, embossed cards, insurance cards – portrait & landscape)
Paper Feeding Detection Multifeed detection with ultrasonic technology; Intelligent Document Protection
Connectivity USB 3.2 GEN 1 (backward compatible with USB 2.0 & USB 3.0)
Software Support Standard:
– Windows software: TWAIN, ISIS, WIA Drivers
– Alaris Smart Touch
– Capture Pro Software Limited Edition (download)

Optional:
– Alaris Info Input Solution
– Alaris Capture Pro Software (Windows only)
– Asset Management Software

Imaging Features Barcode reading (10 types, up to 6 per side)
Perfect Page Scanning
iThresholding & adaptive threshold
Deskew
Autocrop, Relative crop, Fixed crop
Add/remove borders
Electronic color dropout
Dual stream scanning
Enhanced color management & adjustment
Brightness & contrast adjustment
Automatic orientation
Automatic color detection
Background smoothing
Intelligent edge fill
Image merge
Blank page detection & deletion
Streak filtering
Round/rectangular hole fill
Sharpness filter
Auto brightness
Auto white balance
All-color dropout & Multicolor dropout
Long-document scanning up to 3000 mm (118 in.)
Sleeve scanning (for A3 documents)
B/W segmentation
Automatic photo cropping
Multiple document output
Image split
Digital stamping
File Format Outputs TIFF (single/multipage), JPEG, RTF, BMP, PDF, Searchable PDF, TXT, PNG, CSV, Word, Excel
Accessories (Optional) Alaris Carrier Sleeves (5 Pack)
Alaris S2050/2070/2060w/2080w Feed Roller Kit
Alaris S2000 Series Stacking Deflector Accessory
Alaris Integrated A4/Legal Size Flatbed
Alaris Passport Flatbed Accessory
Kodak A3 Size Flatbed (not supported with S2040)
Electrical Requirements 100–240 V (International); 50–60 Hz
Power Consumption Off: < 0.5 W
Sleep: < 3.0 W
Running: < 36 W
Environmental Factors EPEAT Registered; ENERGY STAR Qualified
Operating Temp: 10–35 °C (50–95 °F)
Humidity: 15% – 80% RH
Acoustical Noise Off/Ready: < 20 dB(A)
Scanning: < 50 dB(A)
Recommended PC Configuration Intel Core i3 or faster, at least 4 GB RAM (Windows)
Approvals & Certifications AS/NZS CISPR 32 (Class B RCM mark)
CAN / CSA – C22.2 No 60950-1 (TUV C mark)
CSA-CISPR 32 / ICES-003 (Class B)
China GB4943.1; GB9254 Class B (CCC)
EN55032 ITE Emissions (Class B)
EN55024 ITE Immunity (CE)
EN60950-1 (TUV GS)
IEC60950-1:2005
Taiwan CNS 13438 (Class B), CNS 14336-1 (BSMI)
UL 60950-1 (TUV US)
CFR 47 Part 15 (FCC Class B)
Consumables S2050/2070/2060w/2080w Feed Roller Kit, Cleaning pads, Staticide Wipes, Transport cleaning sheets, Brillianize Detailer Wipes, Carrier Sleeves
Dimensions & Weight Weight: 3.3 kg (7.2 lbs)
Depth: 204 mm (8.0 in.) (without trays)
Width: 312 mm (12.3 in.)
Height: 182.5 mm (7.2 in.) (without trays)
Depth with Input Tray: 269 mm (10.6 in.)
Height with Input Tray: 231.6 mm (9.1 in.)
Operating Systems Supported Windows 10 (32/64-bit)
Windows 8.1 (32/64-bit)
Windows 8 (32/64-bit)
Windows 7 SP1 (32/64-bit)
Windows Vista SP2 (32/64-bit)
Windows XP (customer validated, not formally supported)
Windows Server 2008 R2 (64-bit)
Windows Server 2012 R2 (64-bit)
Windows Server 2016 (64-bit)
Linux (Intel/AMD x86/x64)
Ubuntu (32/64-bit)
OpenSUSE 11.3 (i586, 32-bit), Leap 15.1 (64-bit)
SUSE Linux Enterprise Desktop 12.2 (64-bit), 15 SP1 (64-bit)
NeoKylin OS versions (various: NKLD-V7_U2-ZX64, NeoKylin 6.0 builds, i586 and x86_64)
Citrix Certified
Notes * Throughput speed depends on driver, OS, PC, and processing features.
** Maximum supported document size depends on output resolution and compression chosen.

Overview

Simple information capture to streamline your processes

Digital transformation starts with information capture. Imagine document scanning that speeds and simplifies your business processes. The Alaris S2000 Series Scanners are built to let users capture information anywhere, with superior image quality and data accuracy. Its the perfect solution when you need to get information into your business processes quickly.

Faster, easier scanning leaves more time for business

The Alaris S2000 Series Scanners enhance your productivity by handling more of the work traditionally done by people, computers and mobile devices.

  • Embedded Image Processing in the scanner delivers crisp, high-quality images without depending on your computer.
  • Active Feed technology aligns the leading edges of pages to avoid misfeeds and multi feeds, and Controlled Output Stacking places paper neatly in the output tray, so your team spends less time dealing with documents and more time on work that matters.

Document and information handling you can trust

Ensure reliable data quality at the point of capture through a combined approach of hardware and software technologies.

  • Intelligent Exception Processing1 handles immediate validation of forms so any missing information can be identified and fixed at the point of transaction.
  • Intelligent Document Protection and multi-feed sensor technology make scanning virtually jam-free and document-damage-free.
  • Industry-standard enterprise security protocols for scanning over networks protect document images and data in transit.

Capture that streamlines your business processes Document capture integrates smoothly and conveniently into your normal workflow.

  • Intelligent Barcode Reading produces the most accurate data extraction results and takes the complexity out of document preparation.
  • Convenient push and pull scanning options allow users to scan from business applications or send images directly to applications from the scanner.
  • Mobile scanning enables your workforce to capture documents from their mobile devices or tablets.

Easy to set up, easy to use

An intuitive color interface and predefined job setups2 simplify the lives of users and network administrators.

  • Predefined job setups let users change scanner configuration at the push of a button or by scanning auto-generated QR codes.
  • Connect to various applications such as Dropbox, Salesforce, OneDrive, SharePoint, SharePoint Online, Box, Google Drive, and more.
  • Network models, including wireless connectivity, enable multiple users to easily share scanners in a distributed environment.

Information capture that evolves with your business

The S2000 Series Scanners are designed to fit seamlessly into your business environment and adapt as your needs change.

  • Integrate easily using our Web API, so no device drivers need to be installed on the host computer, tablet, or mobile device.
  • Kodak Asset Management Software helps administrators monitor and manage scanners over the network.
