| Specification | Details |
|---|---|
| Product Type | Smart Scanner |
| Scanning Materials | Documents, Books, Magazines, Forms, Invoices, Certificates, Business cards and Sculpture object |
| Sensor | CMOS |
| Pixel | 38M |
| Resolution | 7168 × 5376 |
| DPI (Default) | 410 |
| Scanning Format | 480 × 360 mm (18.9 × 14.2 inch) |
| Maximum Scanning Format | 480 × 360 mm (18.9 × 14.2 inch) |
| Reference Scanning Thickness | A3 (420 × 297 mm): supports 35 mm A4 (271 × 195 mm): supports 50 mm |
| Scan Speed | Flat single page ≈ 1.5s/page; Books ≈ 1.5s/dual pages |
| Pre Scan | 0s |
| Image Format | JPG, PDF, TIFF |
| Color Bit Depth | 24 bits |
| Export Format | JPG, PDF, Searchable PDF, Word, Excel, TIFF, PNG, BMP |
| Video Streaming Format | MJPG |
| Preview | PC-Visual presenter: 1920 × 1080 @30FPS PC-Scanning: 1536 × 1152 @20FPS |
| USB | USB 2.0 High-Speed |
| Light Source | Natural light and LED lights |
| Top LED Lights | ✔ |
| Side Lights | ✔ |
| Focus Mode | Fixed focus |
| Scanning Access | Device Control, Software triggering, Hand button, Foot pedal |
| System Support | Windows XP / 7 / 8 / 10 / 11 (32/64-bit); macOS 10.13 and above |
| Processor | Dual core openrisc 32bit |
| Laser-Assisted | 3 laser rays |
| DDR | 1G bit |
| Image Cache | Hi-Speed DDR |
| LCD | 2.4″, 4:3, 320 × 240 |
| MIC | ✔ |
| Buzzer | ✔ |
| Hand Button | ✔ |
| Foot Pedal | ✔ |
| Black Document Pad | ✔ |
| Power | Input: AC 100–240V 50/60Hz; Output: DC 9V / 1.5A |
| OCR | ✔ |
| OCR Languages | Supports more than 180 languages |
| Visual Presenter | 3840×2160p@30Hz; 1920×1080p@60Hz / 50Hz; 1920×1080i@60Hz / 50Hz; 1280×720p@60Hz / 50Hz; 720×576p@50Hz |
| Flattening Curve | ✔ |
| Smart Paging | ✔ |
| Smart Tilt Corrections & Auto-Cropping | ✔ |
| Professional Trimming | ✔ |
| Background Purifying | ✔ |
| Finger Removal | ✔ |
| Color Mode | Auto Enhance, Color, B&W, Grayscale, Stamps, Patterns |
| Auto-Scan | ✔ |
| Manual Selection Scanning | ✔ |
| Video Recording | ✔ |
| Element | 3G2P+IR |
| Sensor Size | 1/2″ |
| EFL | 4.55mm |
| BFL | >3.4mm |
| F/NO | 3.2 |
| IR Cut | 650±10nm |
| Field of View | 82° |
| Distortion | <0.5% |
| Product Appearance | Black |
| Product Dimensions | 375 × 220 × 390 mm (L × W × H) |
| Weight | 1.5 kg (Net) |
| Packaging List | Scanner, Side lights, USB cable, Power adapter, Hand button, Foot pedal, Black document pad, Specialized finger cots, CD, Getting Started Guide |
CZUR ET Max
- Two Pages in 1.5s
- 16-38MP HD Camera
- Up to A3 Size
- OCR by ABBYY
- Anti-Reflection
- Multiple Operating Modes
- Multi-Material Compatibility
- Visual Presenter
- HDMI(ET24/25Pro/ET Max)
Overview
The CZUR ET Max is a high-performance smart book and document scanner built for fast digitization, intelligent processing, and professional presentation. Designed for offices, educational institutions, libraries, and home workspaces, it delivers powerful scanning and visual presentation in a single, space-saving device.
With support for A3-size documents, rapid dual-page capture, and advanced image optimization, ET Max makes converting physical content into high-quality digital files effortless and reliable.
Fast, Non-Destructive Book Scanning
The CZUR ET Max is optimized for bound books and thick documents, allowing users to scan without flattening or damaging pages. Its intelligent system captures two pages in as little as 1.5 seconds, while the flattening curve algorithm automatically corrects page warping for a clean, natural result.
Features such as automatic page-turn detection, smart tilt correction, and auto-cropping ensure accurate scans with minimal manual adjustments.
Powerful OCR & Smart Recognition
Equipped with advanced OCR technology supporting over 180 languages, the ET Max transforms scanned pages into searchable, editable documents. It also supports barcode and QR code recognition, making it suitable for logistics, archiving, and administrative work.
For business cards and multi-item scans, smart cutting and splitting automatically separates content, while intelligent page completion enhances damaged or incomplete pages.
Visual Presenter for Teaching & Meetings
More than just a scanner, the CZUR ET Max functions as a real-time visual presenter. With HDMI output, it can project documents, books, and objects directly onto larger displays, making it ideal for classrooms, training sessions, and corporate presentations.
The device is also compatible with Zoom, enabling smooth online demonstrations, remote teaching, and document sharing during virtual meetings.
Versatile Use Across Industries
The CZUR ET Max is designed to perform across a wide range of professional environments, including:
-
Laboratories & Research Facilities
-
Libraries & Documentation Centers
-
Home Offices
-
Accounting & Finance Departments
-
HR & Administrative Offices
-
Meeting Rooms & Classrooms
It easily handles books, magazines, receipts, blueprints, newspapers, certificates, and official documents.
Built to Improve Workflow Efficiency
With features like batch PDF generation, auto-scan, side lighting for shadow reduction, and seamless document sharing, the CZUR ET Max helps teams work faster while maintaining high output quality.
Combining speed, intelligence, and presentation capability, the CZUR ET Max is a reliable solution for modern document digitization and professional collaboration.
