Canon imageFORMULA DR-C225W Document Scanner

Canon imageFORMULA DR-C225W Document Scanner - Image 2

Canon imageFORMULA DR-C225W Document Scanner

20 ppm | 30 sheets ADF
Wireless, ADF
Max paper size: A4

Specifications	Details
Type	Desktop Type Sheet Fed Scanner
Scanning Sensor Unit	CMOS CIS 1 Line Sensor
Optical Resolution	600 dpi
Light Source	RGB LED
Scanning Side	Simplex / Duplex / Folio / Skip Blank Page
Interface	High speed USB 2.0, Wi-Fi (Windows, iOS, Android)
Dimensions (W × D × H)	Tray Closed: 300 x 156 x 220 mm Tray Opened: 300 x 235 x 339 mm
Weight	Approx. 2.8 kg
Power Consumption	Scanning: 12.8 W or less Sleep mode: 1.9 W or less Power tuned off: 0.5 W or less
Environmental Compliance	RoHS and ENERGY STAR
Connection Mode	Access Point Mode and Station Mode
Wi-Fi Security	Authentication: Open, Shared, WPA (PSK), WPA2 (PSK) Encryption: WEP (64/128), TKIP/AES
Data Rates	IEEE802.11b: Max 11 Mbps IEEE802.11g: Max 54 Mbps IEEE802.11n: Max 300 Mbps
Black and White Speed	25 ppm / 50 ipm
Colour Speed	25 ppm / 50 ipm
Output Resolution	150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi
Auto Resolution Setting	Yes
Colour Mode	Detect Automatically, Black & White, Error Diffusion, Advanced Text Enhancement I, Advanced Text Enhancement II (Windows only), 256-Level Grayscale, 24-bit Colour
Daily Duty Cycle	Approx. 1,500 scans/day
Image Processing	Background Smoothing, Prevent Bleed Through/Remove Background, Erase Shadow, Colour Dropout (RGB), Colour Enhancement (Red), Moiré Reduction, Double Feed Detection (Ultrasonic Sensor / By Length), Automatic Page Size Detection, MultiStream, Prescan, Text orientation recognition, Deskew, Image Rotation, Job Setting
Windows	ISIS / TWAIN Driver (Windows 2000 / XP Pro / XP Home / Vista / 7 / 8 / 10), CaptureOnTouch, Nuance eCopy PDF Pro Office, Nuance PaperPort, Nuance OmniPage, Presto! BizCard Reader, Plug-in: Evernote, SharePoint, GoogleDocs, SugarSync, Dropbox, OneDrive, EMC Captiva Cloud Runtime controls
Mac (USB)	TWAIN Driver, CaptureOnTouch, Presto! PageManager, Presto! BizCard Reader, Plug-in: Evernote, SharePoint, GoogleDocs, SugarSync, Dropbox, OneDrive
Consumables	Exchange Roller Kit
Accessories	Flatbed Scanner Unit 101, Flatbed Scanner Unit 201, Silex SX-DS-4000U2
Width	J-Path: 50.8 – 216 mm, Straight-Path: 50.8 – 216 mm
Length	J-Path: 70 – 356 mm, Straight-Path: 53.9 – 356 mm
Thickness	J-Path: 0.06 – 0.15 mm (52 -128 g/m²), Straight-Path: 0.05 – 0.25 mm (40 – 209 g/m²)
Long Document Mode	Straight-Path: 3,000 mm max.
Card Scanning	Straight-Path: 53.9 x 85.5 x 0.76 mm (Embossed card supported)
Paper Separation	Retard Roller Method (Reversing Separator Roller)
Feeder Capacity	30 Sheets (80 g/m²)
Power Requirements	AC 100-240V (50/60Hz)
Operating Environment	10 – 32.5 °C (50 – 90.5 °F), Humidity: 20 – 80% RH

Overview

The DR-C225W’s built-in Wi-Fi allows wireless scanning from mobile, tablet and PC devices. Ideal for sharing among office users, capturing documents at customer retail points and scanning in the home.

Benefits

Ultra compact footprint with a unique J-Path design
High-speed Wi-Fi scanning of up to 50ipm
Full software pack for all your scanning needs
Advanced image processing features
Simple, and easy scanning thanks to intuitive features

Flexible capture and sharing

The DR-C225W with built-in Wi-Fi delivers a better customer experience and faster decision making. It enables iPads, iPhones and Android devices to efficiently batch-capture documents directly at the point-of-sale. Important customer data can quickly be validated and immediately sent into cloud-based business workflows and information management systems for faster processing. Businesses can share the DR-C225W wirelessly among corporate departments or small offices. The easy-to-use Wireless Connection Setup tool enables a smoother switching between Access Point Mode and Station Mode (Infrastructure mode). The DR-C225W can also operate using a standard USB connection.

Compact profile, inspired design

Thanks to its unique vertical J-Path document feeding design, the DR-C225W uses less desk space when scanning. The scanner can be conveniently positioned on a small narrow desk, a window-shelf or at customer retail points where space may be restricted.

Fast, versatile scanning

To help teams work quickly and efficiently, the DR-C225W offers high speed, double-sided scanning of up to 50ipm in Wi-Fi mode.Â¹ The 30-sheet automatic document feeder, incorporating ultrasonic double-feed detection, reliably processes a batch of mixed documents. The selectable straight feeding path enables easy scanning of ID cards, photos and 3m long paper.

Advanced image processing

The DR-C225W includes advanced image processing features, including auto color detection, text enhancement and deskew. MultiStream technology allows simultaneous image outputs in different scanning modes.

CaptureOnTouch

Get a simpler and more intuitive scanning experience with the CaptureOnTouch software’s step-by-step, icon-based user interface. Newly enhanced features put a range of powerful yet easy-to-use document scanning and editing capabilities at your fingertips. In Full Auto Mode, CaptureOnTouch automatically applies the ideal scanning settings for the document content.

CaptureOnTouch Mobile

This free, downloadable mobile app lets you scan batches of documents directly to your mobile/tablet device, including advanced image processing such as auto document size detection, deskew and blank page deletion.

1 Scan speeds may vary dependent on Wi-Fi network.
