| Specification | Details |
|---|---|
| Chipset | Intel B860 |
| CPU | Supports Intel Core Ultra Processors (Series 2) Socket LGA 1851 |
| Memory | |
| Configuration | 4x DDR5 UDIMM, Maximum Memory Capacity 256GB |
| Memory Support | DDR5 8800 – 6400 (OC) MT/s / 6400 – 4800 (JEDEC) MT/s |
| Max Overclocking Frequency | 1DPC 1R: Up to 8800+ MT/s 1DPC 2R: Up to 7200+ MT/s 2DPC 1R: Up to 6400+ MT/s 2DPC 2R: Up to 5600+ MT/s |
| Features | Supports Intel POR Speed and JEDEC Speed Supports Memory Overclocking and Intel XMP 3.0 Supports Dual-Controller Dual-Channel Mode Supports Non-ECC, Un-buffered Memory Supports CUDIMM |
| Notes | The DIMM slots on this motherboard have single-sided latches. Memory compatibility and supported speeds depend on the CPU and memory configuration. Refer to the Memory Compatibility List at MSI Support. |
| Onboard Graphics | |
| Ports | 1x HDMI Supports HDMI 2.1, maximum resolution 4K 60Hz* 1x DisplayPort Supports DisplayPort 1.4, maximum resolution 4K 60Hz* 1x Type-C DisplayPort Thunderbolt 4 port supports DisplayPort 2.1 (UHBR20) over USB Type-C, maximum 4K@120Hz / 8K@60Hz* *Available only with processors featuring integrated graphics. Specifications may vary depending on CPU installed. |
| Expansion Slots | |
| Slots | 4x PCI-E x16 Slots PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x1 (From Chipset) |
| Audio | |
| Codec | Realtek ALC897 Codec |
| Channels | 7.1-Channel High Definition Audio |
| Storage | |
| Configuration | 3x M.2 M.2_1 (From CPU): PCIe 5.0 x4, supports 2280/2260 devices M.2_2 (From Chipset): PCIe 4.0 x4, supports 2280/2260/2242 devices M.2_3 (From Chipset): PCIe 4.0 x2, supports 2280/2260 devices 4x SATA 6G |
| Notes | * Refer to the manual for M.2 SSD heatsink restrictions. |
| RAID | |
| Support | Supports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices |
| Onboard Thunderbolt | |
| Port | 1x Thunderbolt 4 Port (Rear) |
| Performance | Supports up to 40Gbps transfer rate with Thunderbolt devices Supports up to 20Gbps with USB4 devices Supports up to 10Gbps with USB 3.2 devices Supports 5V/3A (15W) power charging Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices Supports up to 8K display output |
| USB | |
| Configuration | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type-A (Rear) 4x USB 5Gbps Type-A (Front) 2x USB 10Gbps Type-A (Rear) 1x USB 10Gbps Type-C (Front) |
| LAN | |
| Port | Realtek 8126 5Gbps LAN |
| Internal I/O | |
| Connectors | 1x Thunderbolt 5 Card Connector (JTBT5, supports RTD3) 1x ATX Power (ATX_PWR) 2x CPU Power (CPU_PWR) 1x PCIe Power (8-pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fans 2x Front Panels (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x COM Port (JCOM) 1x Tuning Controller Connector (JDASH) 2x Addressable V2 RGB (JARGB_V2) 1x RGB LED (JRGB) 1x TPM Header (Supports TPM 2.0) 4x USB 2.0 Ports 4x USB 5Gbps Type-A Ports 1x USB 10Gbps Type-C Port |
| Wireless LAN & Bluetooth | |
| Type | Intel Wi-Fi 7 |
| Module | Pre-installed in the M.2 (Key-E) slot |
| Performance | Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a / b / g / n / ac / ax / be Supports Bluetooth 5.4**, MLO, 4KQAM |
| Notes | * 6GHz band support depends on country regulations; Wi-Fi 7 available in Windows 11 version 24H2. ** Bluetooth 5.4 support schedule depends on Microsoft Windows 11 update plan. |
| LED Features | |
| Indicators | 4x EZ Debug LED |
| Back Panel Ports | |
| Configuration |
|
| Operating System | |
| Support | Windows 11 64-bit |
| Box Content | |
| INCLUDES |  |
| PCB INFO | |
| ATX 243.84mmx304.8mm |
|
