| Specification | Details |
|---|---|
| Technology | |
| Scanner Type | Flatbed Scanner, Sheetfed Scanner |
| Optical Resolution | 1,200 DPI x 1,200 DPI (Horizontal x Vertical) |
| ADF Minimum Document Size | 100 mm x 148 mm (Horizontal x Vertical) |
| ADF Maximum Document Size | 216 mm x 1,016 mm (Horizontal x Vertical) |
| Paper Formats | A4 (21.0×29.7 cm), A5 (14.8×21.0 cm), A6 (10.5×14.8 cm), B5, Letter, Legal, Executive |
| Scanning color depth | Input: 48 Bits Color / 16 Bits Monochrome, Output: 24 Bits Color / 8 Bits Monochrome |
| Ultrasonic Sensor | Yes |
| Category | Network & Wifi, High Capacity, General Office |
| Light Source | ReadyScan LED technology |
| LCD Display | Epson Network Interface Panel |
| Scan speed | |
| Scanning Speed | Monochrome: 40 pages/min – Color: 40 pages/min measured with Size: A4, Resolution: 200 / 300 dpi; Monochrome: 80 image/min – Color: 80 image/min measured with Size: A4, Resolution: 200 / 300 dpi |
| Paper / Media Handling | |
| Paper Setting Capacity | 100 Sheets |
| Paper weight | Auto loading: 50 – 128 g/m² |
| Reliability Daily Duty Cycle | 4,000 pages |
| Automatic Document Feed | 100 pages |
| Duplex Scan | Yes |
| Scanning Features | Skip blank page, Pre-defined scanning settings, Automatic area segmentation, Automatic de-skew, Automatic B/W colour original detection, Dual Image Output (Windows only), Auto-rotation, Text enhancement, Edge fill, Advanced cropping feature for Auto size, Unsharp Mask (USM), Descreening |
| Output formats | JPEG, TIFF, multi-TIFF, PDF, PDF / batch, searchable PDF, secure PDF, PDF/A |
| File compression features | Hardware JPEG compression, TIFF Compression (JPEG(7), CITT G4, LZW), PDF Compression |
| Advanced document integration | Scan to Email, Scan to FTP, Scan to Microsoft SharePoint®, Scan to Print, Scan to Web folders, Scan to Network folders |
| Connectivity | |
| Interfaces | Ethernet interface (100 Base-TX / 10 Base-T) |
| Network Interface Panel / Unit | Built-in |
| Ethernet settings | 10BASE-T / 100BASE-TX / 1000BASE-T / Full-duplex / Half-duplex |
| Panel type | 5-line LCD with Push Scan features |
| Protocol support | TCP/IP, DHCP, DNS, SNMP, SLP |
| IPv6 support | Yes |
| Push scan features | Yes (with Document Capture Pro solutions) |
| Panel Lock with password | Yes (with Document Capture Pro solutions) |
| General | |
| Supply Voltage | AC 100 V – 240 V, 50 Hz – 60 Hz |
| Product dimensions | 495 mm x 360 mm x 217 mm (Width x Depth x Height) |
| Product weight | 10.28 kg |
| Drivers | TWAIN, WIA, ISIS (Web download), SANE (Linux), ICA (Mac) |
| Included Software | Epson Document Capture Pro (Windows only), Epson Document Capture Pro Server (on free download), Epson Event Manager (Mac Only), Epson Scan |
| Compatible Operating Systems | Citrix XenApp 5.0, Citrix XenApp 6.0, Mac OS 10.4+, Mac OS X 10.11.x, Presentation Server 4.5, Terminal Service, Windows 7, Windows 7 x64, Windows 8, Windows 8.1, Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2008 R2, Windows Vista, Windows Vista x64, Windows XP, Windows XP x64, Windows Server 2003 R2 |
| Power consumption | 44.5 Watt, 12 Watt (economy), 1.6 Watt (standby) |
| Noise Level | Operation (Roll): 67.9 dB (A) |
| Supported Humidity | Operation 10% – 80%, Storage 10% – 85% |
| Supported Temperature | Operation 5° C – 35° C, Storage -25° C – 60° C |
| What’s in the box | Epson Network Interface Panel, Main unit, Power cable, Setup guide, Software (CD), USB cable, User manual (CD), Warranty document |
| Options | Roller Assembly Kit |
| Other | |
| Warranty | 12 months On-site service |
Epson WorkForce DS-7500N
- High speed scanner Scan up to 40ppm/80ipm
- High capacity ADF 100-page ADF capacity
- Hassle-free Double Feed Detection
- Network-ready Network Interface Panel
- Push Scan features Simple one-touch scanning*1
Overview
High Speed A4 networked scanner
Improve document workflow processes with this reliable A4 network-ready departmental scanner
Engineered to integrate seamlessly into document management systems, this networked document scanner ensures heavy-duty scanning jobs are performed quickly, efficiently & effortlessly.
SKU: B11B205331BU
The Epson WorkForce DS-7500N can handle large batches of documents in a single go, quickly and efficiently. With a scanning speed up to 40ppm/80ipm, this departmental scanner ensures fast and trouble-free scanning due to a 100-page ADF, one-pass duplex scanning, and Double Feed Detection.
Epson Document Capture Pro makes it easy to integrate high-speed scanning into your document management system, speeding up workflow and enabling users to capture, convert and distribute scanned information in virtually any document repository or document management system.
The scanner and its features can be shared between multiple users using the built-in Network Interface Panel. Combined with Document Capture Pro, the Network Interface Panel allows users to benefit from Push Scan features and customise ‘scan to’ job functions, such as ‘scan to email’ or ‘scan to Microsoft SharePoint®’, among others*2. You can also benefit from its optional Push Scan features to increase productivity. These features enable complicated tasks to be carried out effortlessly, increasing users’ acceptance and eliminating training requirements.
Epson ReadyScan LED technology eradicates warm-up time, guarantees an absence of mercury, and lowers power consumption. These elements create an environment friendly device for your office workspace.
