Document Scanner

Canon imageFORMULA DR-C340/C350

Ultra-Compact High-Speed Desktop Scanner

Up to 100 ipm duplex scanning
100-sheet automatic document feeder
Supports cards, passports, long documents
Advanced image enhancement technology
Compact design with USB Type-C
Up to 7,000 scans daily

Category: Document Scanner Brand: Canon

Sales Enquiry

Specifications	Details
Type	Desktop Sheet-Fed Scanner
Scanning Element	Contact Image Sensor (CIS)
Light Source	RGB LED
Scanning Side	Simplex / Duplex
Greyscale Scanning Speed	DR-C340: 40 ppm (Simplex) / 80 ipm (Duplex) DR-C350: 50 ppm (Simplex) / 100 ipm (Duplex)
Colour Scanning Speed	DR-C340: 40 ppm (Simplex) / 80 ipm (Duplex) DR-C350: 50 ppm (Simplex) / 100 ipm (Duplex)
Scanning Modes	Black and White, Error Diffusion, Advanced Text Enhancement, Advanced Text Enhancement II, Active Threshold, 256-level Greyscale, 24-bit Colour
Scanner Features	Active Threshold, Folio Merge, Highlighter Enhancement, Document with Photo Mode, Colour Unevenness Reduction, Background Fill, Colour Balance Adjustment Function
Output Resolution	100 / 150 / 200 / 240 / 300 / 400 / 600 / 1200 dpi
Suggested Daily Volume (SDV)	DR-C340: 5,500 scans/day DR-C350: 7,000 scans/day
Plain Paper Size	Width: 50 – 216 mm Length: 54 – 356 mm Up to 6,096 mm with Long Document Mode
Business Card Size	Width: 50 – 55 mm Length: 85 – 91 mm
Card Size (ISO Standard)	54 x 86 mm
Plain Paper Thickness & Weight	Page Separation / Non-Separation Mode: Weight: 27 – 413 g/m² Thickness: 0.04 – 0.49 mm
Business Card Thickness & Weight	Weight: 128 – 255 g/m² Thickness: 0.15 – 0.3 mm
Card Thickness	Up to 1.4 mm
ADF Capacity	100 Sheets
Interface	USB 3.2 / USB 3.1 / USB 3.0 / USB 2.0 (Type-C™ Connector)
Software	ISIS, TWAIN and WIA Driver, CaptureOnTouch Pro, Canon imageFORMULA Driver Setting Tool, DR Management Tool (Download Only)
Power Requirements	AC 220-240V (50/60Hz)
Power Consumption (Scanning)	15.6 W or Less
Power Consumption (Sleep Mode)	0.6 W
Power Consumption (Power Off)	0.1 W or Less
Operating Temperature	10°C to 32.5°C
Operating Humidity	20% to 80% RH
Dimensions (Trays Closed)	283 x 223 x 218 mm
Dimensions (Trays Open)	283 x 551 x 366 mm
Weight	Approx. 3.2 kg (Without AC Adapter)
Options / Consumables	Exchange Roller Refill Kit, Carrier Sheet (A4), Passport Carrier Sheet
Accessories	Flatbed Scanner Unit 102 (A4)

Overview

The Canon imageFORMULA DR-C340/C350 is a powerful desktop document scanner engineered for organizations that demand fast, reliable, and space-efficient document digitization. Designed with an ultra-compact footprint, it fits seamlessly into offices, reception counters, retail environments, financial institutions, healthcare facilities, and government departments where desk space is limited but productivity is essential.

With high-speed duplex scanning, advanced image processing technology, and a robust 100-sheet Automatic Document Feeder (ADF), the DR-C340/C350 delivers exceptional performance for high-volume document workflows. Whether scanning invoices, contracts, forms, ID cards, passports, or long documents, it ensures accurate and efficient digital capture with minimal user intervention.

Key Features

High-Speed Duplex Scanning

Boost productivity with rapid single-pass duplex scanning that captures both sides of a document simultaneously.

DR-C340: Up to 40 pages per minute (80 images per minute)
DR-C350: Up to 50 pages per minute (100 images per minute)

Ultra-Compact Design

With a narrow width of just 283 mm, the DR-C340/C350 is among the most space-saving scanners in its class, making it ideal for crowded desks, customer service counters, and front-office environments.

Large 100-Sheet ADF Capacity

The high-capacity Automatic Document Feeder allows users to process large document batches efficiently, reducing interruptions and increasing workflow productivity.

Versatile Media Handling

Designed to accommodate a wide variety of document types and sizes, including:

Standard office documents
Ultra-thin paper
Long documents up to 6,096 mm
Business cards
Plastic ID cards
Passports and travel documents

Advanced Image Processing

Intelligent image enhancement technologies automatically optimize scanned output for improved readability and reduced file sizes. Features include:

Auto Colour Detection
Auto Resolution Adjustment
Advanced Text Enhancement
Background Fill
Colour Balance Correction
Active Threshold Processing

These tools help ensure clear, professional-quality digital documents every time.

User-Friendly Operation

An intuitive control panel and customizable one-touch scan jobs simplify daily operation. Users can quickly launch predefined workflows and scan tasks with minimal training.

Powerful Workflow Integration

Bundled software supports seamless integration into existing business processes with features such as:

OCR (Optical Character Recognition)
Barcode Recognition
2D Code Recognition
Direct cloud connectivity
Automated document routing and processing

Reliable High-Volume Performance

Built for demanding business environments, the scanners support recommended daily volumes of:

DR-C340: Up to 5,500 scans per day
DR-C350: Up to 7,000 scans per day

Advanced double-feed detection and recovery functions help minimize downtime and maintain uninterrupted operation.

Modern Connectivity

Equipped with USB Type-C connectivity and support for USB 3.2, USB 3.1, USB 3.0, and USB 2.0 standards, the DR-C340/C350 offers fast and flexible integration with modern workstations.

Energy-Efficient and Environmentally Conscious

Designed with sustainability in mind, the scanner features low power consumption, ENERGY STAR® compliance, recyclable packaging materials, and redesigned consumables that help reduce environmental impact.

Ideal Applications

Financial Services
Healthcare Facilities
Government Offices
Logistics & Transportation
Retail Operations
Hospitality Businesses
Corporate Document Management
Front Desk & Reception Areas

Transform Paper into Productivity

The Canon imageFORMULA DR-C340/C350 combines compact design, exceptional scanning speed, intelligent document processing, and versatile media support to help organizations accelerate digital transformation and streamline document workflows. Whether for everyday office scanning or high-volume document capture, it delivers reliable performance in a space-saving package.
